Caton has over 50 years of high-voltage connector and cable assembly design and manufacturing experience. Our standard product lines feature voltage ranges of 1kV to 70kV, all while maintaining corona-free performance. If you require something more unique, Caton has a solution for you. In addition to our standard product lines, we have designed hundreds of custom high-voltage cable assemblies and connectors.
Our high-voltage connectors are designed to withstand a variety of applications and environments, from naval ship board applications, to high-power microscopes in clean rooms.
14 Series Single-Pin High-Voltage Connector
- 10 – 45 KVDC
- 4 – 10 AMPS
- Push-Pull Mating
- Corona Free Designs
17 Series Single-Pin High-Voltage Connector
- 15 – 40 KVDC
- 4 – 10 AMPS
- Bulkhead and In-Line Screw Coupling
- High Voltage Feedthrough available
- Corona Free Designs
19 Series Single-Pin High-Voltage Connector
- 60 KVDC, 20 KVRMS
- 26 AMPS
- Bulkhead and In-Line Screw Coupling
- High Voltage Feedthrough available
- Corona Free Designs
16 Series Multi-Pin
High-Voltage Connector
- 19 Standard Pin Configurations
- 10 Shell Sizes
- 10 – 50 KVDC
- 4 – 85 AMPS
- Bulkhead and Inline Screw Mating
- Corona Free Designs
High-Voltage Wire
UL Style 3239
- Up to 50 kVDC
- 20-12 AWG
- Corona Free Designs
Dual Extruded
- Up to 80 KVDC
- 22-8 AWG
- Semi-conductive silicone layer
- Corona Free Designs
Custom Solutions
All of Caton’s Standard products can be easily modified to meet your specific needs.
